Wytronn 18X DVD / CD Duplicator Controller



Wytron Controller
Wytron DVD Duplicator
7 Targets
11 Targets

Product Feature:

  1. Ultimate design for 7-target DVD or 11-target duplicating controller card.
  2. Eight fully independent Ultra-DMA channels for twelve ports on-board to connect up to 7 targets of 18x DVD writer for max. speed of 18x DVD writing(7 targets only).
  3. Twelve fully independent Ultra-DMA channels for twelve ports on-board to connect up to 11 targets of 18x DVD writer for max. speed of 18x DVD writing(11 targets only).
  4. One isolated/independent channel for master ROM reader and hard drive for reading and providing data to targets.
  5. 64MB large cache-buffer SDRAM on-board to ensure of data's fluency from master to targets.
  6. Friendly user interface, easy understanding and operation by large-scale 20 x 2 LCD display.
  7. Support RS-232 ports to enable the connection of robot arm for automatic DVD duplication (approval of robotic arm required and needs optional COMM module to convert from 4-pin to 9-pin RS-232 connection).
  8. Max. compatibility for writers in the market such as Pioneer, Asus, BenQ, LG, Lite-ON, NEC, Sony, Plextor, etc.
  9. Stability and robust structure, enable long-life continuous usage.
  10. Easy BIOS upgrade available.
  11. Multi-language supported such as English and Spanish.
  12. CD-R/CD-RW/DVD-R/DVD-RW/DVD-R DL/DVD+R/DVD+RW/DVD+R DL writing capability and write speed depend on those CD/DVD writers installed by users. Also the write speed may drop to lower speed when unqualified DVD media used.

Product Specification:

Model DVD-669 (7 Targets) or DVD-689(11 targets)
Targets 7 or 11
Hard Drive Support Yes (PATA Hard Drive)
Writer Support All major IDE / PATA DVD or CD Writers
Display 20 x 2 LCD
Buffer Memory 64 MB
Format Support CD-R, CD-RW
Business Card CD-R, Mini CD-R
DVD-R, Mini DVD-R, DVD-RW, DVD-R DL
DVD+R, DVD+RW, DVD+R DL
Language Support English, Spanish
Operating Humidity 20% ~ 80%
Temperature 40 C (104 F) / 5 C (41 F)
Regulation FCC, CE, RoHS

Package Content:

  • Duplicator controller
  • IDE cable(s)
  • User Manual
  • Installation Guide

Warranty:

  1. BuyController will offer 1 Year Manufacture Parts and Labor Warranty.
  2. All sales are final and warranty period starts from the invoice date.
  3. Customer must request a RMA number before sending the item back to us for service. Customer can request a RMA number by calling +1-650-490-3971.
  4. Customer must write the RMA number on the box. Box without RMA number will be returned.
  5. RMA will be either fixed or replaced during the warranty period.
